Cable drum 1" - type IV - Motion range

Is used for the attachement of 2 mm aircraft wire. Material: Steel Galvanized

A durable aircraft cable for shading systems.Material: Steel Galvanized

A durable, stainless aircraft cable for cable drive shadings systems. Thanks to these characteristics it specially fits external constructions. It is compatible with our slip joint. Tensile strength:Material: Stainless Steel

This steel tube is used as a drive shaft in shading and ventilation systems in large greenhouses. Due to its wall thickness of 3.25 mm, it is very resistant against torsion. The tube connector halves within our product range are used to connect the tubes. Diameter: 33.5 mm Wall thickness: 3,25 mm Length: 6050 mm Material: Steel, galvanized

This steel tube is used as a drive shaft for ventilation systems and large shading systems in greenhouses.Due to its wall-thickness of 2,50 mm, it is resistant against torsion.The tubes can be easily connected by inserting them into each other through their swaged ends and bolting them afterwards. Bolt M8 x 50 with a nyloc nut M8 are neededDiameter: 1 Wall thickness: 2.5 mmLength: 6500 mmMaterial: Galvanised Steel

This offset bearing has been developed for suspended shading systems with gable end drive. It brings the drive shaft to an optimal position and as a support point enables its rotation. The product has been built to hold trailing load. Material: High impact reistant plastic For mounting you will need the following parts: - M 8 x 70 bolt - M8 nyloc nut

Our vertical bearing shaft supports 1" allows to set the drive shaft as close as possible to the gable end. In such a construction the shading screens do not set against the truss , but lay either over( in suspended system) or below ( in lay- flat system) the square tube, covering the whole area up to the gable end. The dalay of screens is basically not needed.The drive shaft can easily and quickly be pre-assembled on the ground. So dangerous, time-consuming works underneath the roof can be avoided.The bearings are attached onto the square tubes and locked with locking screws. If needed, they can be moved

Application: Joining 34 mm steel tubes in drive shafts Material: Hot-dip galvanized steel for superior strength and corrosion resistance Installation: Screwed together using included M8x50 bolts Highlight: Greater stability and longevity compared to welded joints Packaging Unit: 25 sets 1" Steel Tube Clamp Connectors incl. M8x50 Screws provide a secure and reliable connection for 34 mm steel tubes in drive shaft assemblies. Unlike welded joints, these clamp connectors offer improved durability and structural integrity. Each set includes M8x50 screws for quick installation. Thanks to the hot-dip galvanized finish, the connectors offer excellent corrosion protection, making them well-suited for long-term use in challenging environments.
