Tube clip 19 mm - PU = 2000 pcs.

This lightweight aluminium tube is used in suspended and in lay-flat shading systems as a screen guiding tube. Thanks to its very light aluminium construction it is possible to realise light shading systems, which are specially interesting for greenhouses with a wide truss-spacing. In such greenhouses it is a good alternative to the commonly used 19 mm steel tubes. Material: Aluminium

The lead edge connector 19 S is a convenient, static connection for 19 mm aluminium and steel tubes. The piece is so designed that it can be plugged and fixed through stump bunch marking. Compared to a commonly used bolting-connectors this one can be mounted quicker and easier. However the tubes cannot be disconnected from each other.

This lead edge tube clip connects support wire with 19 mm aluminium tubes in shading systems.

This slip joint gently connects the drive cable with 19 mm aluminium tubes in shading systems. In this model the slipping clutch is realized via a slip joint technique, which protect the drive cable. This technique is especially suitable for greenhouses, where heat can cause stretching of their constructive components, for example, aluminium rain pipes. We deliver the slip joint including bolts, nuts as well as spring and cover plate for 19 mm tubes.

This lead edge cable clip S 19 ensures a firm connection of the drive cable and the 19 mm tube. For mounting M 4x16 ISK bolts are needed.

This lead edge cable clip EXT ensures a strong connection of the drive cable and the 19 mm tube. The extended form of this clip allows to avoid the contact between drive cable and fabric, that can cause damage of the fabric.For mounting M 4x16 ISK bolts are needed.
