Adaptor for tower-roll 50 mm for RW 240

Application: Roll-up tube for single curtain systems in greenhouses Length: 5.00 m Diameter: 50 mm (Type I) Material: Aluminum Features: One groove for inserting shade cloth The Aluminum tube Ø 50 mm Type I – 5.00 m is ideal for single roll-up curtain systems. It features a groove for inserting the shade cloth and is made of lightweight, corrosion-resistant aluminum. Delivered as individual pieces.

Application: Motor mount and counterweight carriage for Tower Roller Plus systems Features: Includes guiding rail cover for added safety Design: Lightweight, compact, and maintenance-free Compatibility: For all standard motors - counterweight matched to system The Tower Roller Plus Roll Console incl. guiding rail cover is the central moving unit in the Tower Roller Plus system. It carries the motor and counterweight, runs on high-strength plastic rollers, and includes a protective cover for the guide rail. Designed for long-lasting, low-maintenance operation in greenhouse environments.

Application: Complete drive unit for roll-up screens and side ventilation systems Weight: 15 kg counterweight System type: Tower Roller Plus Features: Compact design (80 mm depth), integrated cable guide, enclosed counterweight Compatibility: Suitable for all common motors - counterweight is matched accordingly The Tower Roller Plus Set – 15 kg is a complete drive unit for medium to large roll-up screens, side ventilation systems, and partitioning curtains. It features a compact design, integrated cable routing with energy chain, and a fully enclosed counterweight for enhanced safety. Built for durability and minimal maintenance.

Application: Guide rail for motor mount and counterweight in Tower Roller Plus systems Length: 4.00 m Material: Anodized aluminum Features: Integrated slot for plastic safety cover - quick installation Function: Stabilizes and guides the motor console and counterweight The Tower Roller Plus Guide Rail – 4.00 m is a structural component of the Tower Roller Plus drive system. It guides the motor console and counterweight, and includes a slot for a plastic cover to reduce injury risk. Built from anodized aluminum for strength and corrosion resistance.

Application: Maintenance-free gear motor for ventilation, screen, and lifting systems in greenhouses and livestock buildings Material: Robust construction with high protection class IP55 Voltage: 400–450 V, 3-phase Speed: 5 revolutions per minute Limit Switch: Patented linear limit switch system with high switching accuracy Temperature Range: Suitable for ambient temperatures from 0–60 °C Feature: Low-noise operation through optimized gear and worm drive; output shaft compatible with Tower Roller Plus and telescopic systems Ridder Item No.: 532259 The Ridder RW245-37/400-450 Grease Drive is a maintenance-free gear motor designed for ventilation, screen, and lifting systems in greenhouses and livestock facilities. Its robust IP55-rated housing ensures reliable protection against dust and water, even in demanding environments. Operating at 400–450 V and a constant speed of 5 revolutions per minute, the RW245-37 enables precise and dependable motion control. The patented linear limit switch system ensures accurate shaft positioning and high switching precision. The optimized gear and worm drive combination allows for quiet operation and secure self-locking when stationary. The output shaft is specifically designed for direct compatibility with Tower Roller Plus and telescopic systems, eliminating the need for mechanical adaptations. Optionally, the drive position can be transmitted to a climate computer via the RPU PositioningUnit or a potentiometer kit.

Application: Maintenance-free drive for ventilation, shading, and lifting systems in greenhouses and livestock buildings Voltage: 400–450 V, 3-phase Speed: 5 rpm Protection class: IP55 – dust and water resistant End switch: Patented linear limit switch system with high switching accuracy Temperature range: 0–60 °C Features: Quiet operation, self-locking worm gear, optional RPU PositioningUnit or potentiometer kit Ridder Article No.: 502320 The RW245-37 motor gearbox is a rugged, low-maintenance drive unit designed for greenhouse automation. Its precise limit switch system and quiet, self-locking transmission ensure reliable performance in demanding environments.

Application: Compact drive for ventilation, shading, and lifting systems in greenhouses and livestock buildings Voltage: 400–450 V, 3-phase Speed: 3 rpm Protection class: IP55 – dust and water resistant End switch: Integrated linear limit switch system with high switching precision Temperature range: 0–60 °C Features: Self-locking worm gear, quiet operation, optional RPU PositioningUnit or potentiometer kit Ridder Article No.: 502310 The RW243 motor gearbox is a compact and powerful solution for greenhouse automation. Its robust design and precise switching system make it ideal for long-term use in harsh environments.
